136 | INDEXABLE TOOL HOLDERS & BORING BARS

Suitable Carbide Suitable Carbide
Cat No. ISO Designation Shank Size Cat No. ISO Designation Shank Size
Insert Insert
GIT-0031 SCLCR/L 0606 D06 6 x 6 x 60mm CCMT 060204 GIT-0046 SCMCN 0606 D06 6 x 6 x 60mm CCMT 060204
GIT-0032 SCLCR/L 0808 D06 8 x 8 x 60mm CCMT 060204 GIT-0047 SCMCN 0808 D06 8 x 8 x 60mm CCMT 060204
GIT-0033 SCLCR/L 1010 E06 10 x 10 x 70mm CCMT 060204 GIT-0048 SCMCN 1010 E06 10 x 10 x 70mm CCMT 060204
GIT-0034 SCLCR/L 1212 F06 12 x 12 x 80mm CCMT 060204 GIT-0049 SCMCN 1212 F06 12 x 12 x 80mm CCMT 060204
GIT-0035 SCLCR/L 1616 H09 16 x 16 x 100mm CCMT 090304 GIT-0050 SCMCN 1616 H09 16 x 16 x 100mm CCMT 090304
GIT-0062 SCLCR/L 2020 K12 20 x 20 x 125mm CCMT 1204 GIT-0066 SCMCN 2020 K12 20 x 20 x 125mm CCMT 1204
GIT-0078 SCLCR/L 2525 H09 25 x 25 x 150mm CCMT 1204 GIT-0082 SCMCN 2525 K12 25 x 25 x 150mm CCMT 1204

Cat No. ISO Designation Shank Size Suitable Carbide Cat No. ISO Designation Shank Size Suitable Carbide
Insert
Insert
GIT-0036 SCBCR 0606 D06 6 x 6 x 60mm CCMT 060204 GIT-0051 SCSCR 0606 D06 6 x 6 x 60mm CCMT 060204
GIT-0037 SCBCR 0808 D06 8 x 8 x 60mm CCMT 060204 GIT-0052 SCSCR 0808 D06 8 x 8 x 60mm CCMT 060204
GIT-0038 SCBCR 1010 E06 10 x 10 x 70mm CCMT 060204 GIT-0053 SCSCR 1010 E06 10 x 10 x 70mm CCMT 060204
GIT-0039 SCBCR 1212 F06 12 x 12 x 80mm CCMT 060204 GIT-0054 SCSCR 1212 F06 12 x 12 x 80mm CCMT 060204
GIT-0040 SCBCR 1616 H09 16 x 16 x 100mm CCMT 090304 GIT-0055 SCSCR 1616 H09 16 x 16 x 100mm CCMT 090304
GIT-0067 SCBCR 2020 K12 20 x 20 x 125mm CCMT 1204 GIT-0066A SCSCR 2020 K12 20 x 20 x 125mm CCMT 1204
GIT-0081 SCBCR 2525 K12 25 x 25 x 150mm CCMT 1204 GIT-0082A SCSCR 2525 K12 25 x 25 x 150mm CCMT 1204

INDEXABLE BORING BARS
Cat No. ISO Designation Shank Size Suitable Carbide Cat No. ISO Designation Shank Size Suitable Carbide
Insert
Insert
GIT-0041 SCKCR 0606 D06 6 x 6 x 60mm CCMT 060204 GIT-0056 S06F SCLCR/L 6 x 80mm CCMT 060204
GIT-0042 SCKCR 0808 D06 8 x 8 x 60mm CCMT 060204 GIT-0057 S08H SCLCR/L 8 x 100mm CCMT 060204
GIT-0043 SCKCR 1010 E06 10 x 10 x 70mm CCMT 060204 GIT-0058 S10K SCLCR/L 10 x 125mm CCMT 060204
GIT-0044 SCKCR 1212 F06 12 x 12 x 80mm CCMT 060204 GIT-0059 S12M SCLCR/L 12 x 150mm CCMT 060204
GIT-0045 SCKCR 1616 H09 16 x 16 x 100mm CCMT 090304 GIT-0060 S16R SCLCR/L 16 x 200mm CCMT 090304
GIT-0064 SCKCR 2020 K12 20 x 20 x 125mm CCMT 1204 GIT-0061 S20S SCLCR/L 20 x 20 x 125mm CCMT 1204
GIT-0080 SCKCR 2525 K12 25 x 25 x 150mm CCMT 1204 GIT-0084 S25M SCLCR/L 25 x 25 x 150mm CCMT 1204

SPARE CARBIDE INSERT
7 PC SET OF TOOL HOLDERS &
BORING BARS
Shank Suitable
Cat No.
Size Carbide Insert
GIT-0026 6mm CCMT 060204
GIT-0027 8mm CCMT 060204
GIT-0028 10mm CCMT 060204 Cat No. ISO Designation
GIT-0029 12mm CCMT 060204
GIT-0030 16mm CCMT 090304 GCI-CC06 CCMT 060204
GIT-0032A 20mm CCMT 1204 GCI-CC09 CCMT 090304
GIT-0032B 25mm CCMT 1204 GCI-CC12 CCMT 1204
All above are supplied complete with suitable Insert, Screw & Torx Key.
