P. 43
machine TOOLS accessories
indexable tools
144 | INDEXABLE TURNING &
PARTING TOOL SET
7 PCS
Cat No. Size
GIT-7500 8mm
GIT-7501 10mm
GIT-7502 12mm
GIT-7503 14mm
GIT-7504 16mm
GIT-7505 20mm
• SCLCL - 1 Pc
• SDJCR - 1 Pc
• SCLCR - 1 Pc
• SCKCR - 1 Pc
• Boring Bar - 1 Pc
• Parting & Grooving Holder - 1 Pc
• External Threading Tool SER - 1 Pc
145 | INDEXABLE BORING BAR
MINI
Cat No. ISO DESIGNATION Size Suitable Carbide Insert
GIT-9000 S06H SELPR 04 6mm EPMW 040204
• Perfect for holes less than 6.8 mm.
• Length 100mm.
SPARE CARBIDE INSERT
Cat No. ISO Designation
GCI-EPMW EPMW 040204
146 | INDEXABLE TURNING TOOL SET
5 PCS
Cat No. Size Suitable Carbide Insert
GHT-7400 6mm (1/4”) TCMT 1102
GHT-7401 8mm (5/16”) TCMT 1102
GHT-7402 10mm (3/8”) TCMT 1102
GHT-7408 12mm (1/2”) TCMT 1102
GHT-7414 16mm (5/8”) TCMT 1102
• STJCR - 1 Pc
• STJCL - 1 Pc
• STECN - 1 Pc
• STBCR - 1 Pc
• STBCL - 1 Pc
www.garvintools.com 41
