machine TOOLS accessories
hand tools

124 | ENGINEER’S BEARING GBS-0607 Inch Size mm Shape
Cat No.
SCRAPPERS
100
4
Flat
GBS-0608 4 100 Triangular
• Blades are manufactured from high GBS-0609 4 100 Half Round
carbon steel. GBS-0610 6 150 Flat
• Hardened & ground points. GBS-0611 6 150 Triangular
• Used to remove spots & burrs on GBS-0612 6 150 Half Round
machined surfaces. GBS-0613 8 200 Flat
• Handles are manufactured from fine
quality wood & polished. GBS-0614 8 200 Triangular
GBS-0615 8 200 Half Round
GBS-0616 10 250 Flat
GBS-0617 10 250 Triangular
GBS-0618 10 250 Half Round
GBS-0619 12 300 Flat
GBS-0620 12 300 Triangular
GBS-0621 12 300 Half Round
GBS-S607 3Pc Set of 4”Long Flat, Triangular & Half Round
GBS-S610 3Pc Set of 6” Long Flat, Triangular & Half Round
GBS-S613 3Pc Set of 8” Long Flat, Triangular & Half Round
GBS-S616 3Pc Set of 10” Long Flat, Triangular & Half Round
TRIANGULAR FLAT HALF ROUND GBS-S619 3Pc Set of 12” Long Flat, Triangular & Half Round

125 | VALVE SEAT & FACE
CUTTERS
No. Of pcs Sizes of Bore
Cat No. Sizes of Valve seat & face cutters included Inches
in each set Cutters Included
1.5/15 & 1.7/16 (45°) (Supplied with 2 Nos. Guides,
GVC-8238 3Pcs Set 1.3/8 (20°)
1Nos each Handle, rod & Small Pin)
GVC-8239 4Pcs Set 1.5/16, 1.7/16 & 1.3/8 (45°) (Supplied with 2 Nos. 1.3/8 (20°)
Guides, 1Nos each Handle, rod & Small Pin)
1.5/16, 1.3/8, 1-1/2, 1-11/16 (45°) (Supplied with 2
GVC-8240 5Pcs Set 1.9/16 (20°)
Nos. Guides, 1Nos each Handle, rod & Small Pin)
1.3/16, 1.1/4, 1.5/16, 1.3/8, 1.1/2, 1.11/16, 1.1/4 &
1.9/16 (20°), 1.3/4 (45°) & 1.11/16 (30°)
GVC-8241 10Pcs Sets (Supplied with 8 Nos. Guides, 2 Nos each Handle, 2 1.1/4 & 1.9/16
(20°)
rods & Small Pin)
1.3/16, 1.1/4, 1.5/16, 1.3/8, 1.1/2, 1.11/16, 1.1/4 & 1.1/4,
1.9/16 (20°), 1.3/4 (45°) , 1.11/16 (30°) & 2.1/16 (45°)
GVC-8242 12Pcs Set 1.9/16 (20°) &
(Supplied with 8 Nos. Guides, 2 Nos each Handle, 2
rods & Small Pin) 1.3/4 (20°)
1.3/16, 1.1/4, 1.5/16, 1.3/8, 1.1/2, 1.11/16, 1.1/4 & 1.1/4,
GVC-8243 15Pcs Set 1.9/16 (20°), 1.3/4 (45°) & 1.11/16 (30°) ,2.1/16 (45°), 1.9/16 (20°) & • Manufactured from High Grade Carbon Steel,
1.7/16, 1.5/8” & 2.1/8 (45°) (Supplied with 8 Nos.
Guides, 2 Nos each Handle, 2 rods & Small Pin) 1.3/4 (20°) • properly hardened & tempered.
The Cutting Edges of all the cutters are
1.3/16, 1.1/4, 1.5/16, 1.3/8, 1.1/2, 1.11/16, 1.1/4 & 1.1/4, 1.9/16 accurately ground for best results.
GVC-8244 20Pcs Set 1.9/16 (20°), 1.3/4 (45°) & 1.11/16 (30°) ,2.1/16 (45°), (20°), 1.3/4 (20°) • Sets Supplied in Fine Finished wooden box.
1.7/16, 1.5/8” ,2.1/8 (45°), 1.1/8, 1.7/8 & 2.1/4 (45°) & 2” (20°)

Cutting Edge Size Total length
126 | COLD CHISELS GCC-0594 5/16 mm Inch mm
Cat No.
Inch
4
100
8.0
GCC-0595 3/8 9.5 5 125
GCC-0596 1/2 12.7 6 150
GCC-0597 5/8 16.0 6 150
GCC-0598 3/4 19.00 7 175
• Manufactured from GCC-0599 1 25.00 8 200
tool steel.
• Edges are hardened GCC-0600 3/4 19.00 12 300
& ground. GCC-0601 1-1/8 28.00 12 300
