machine TOOLS accessories
tap & reamer wrenches

55 | T - TAP WRENCHES Pull the pin up and

RATCHET TYPE
adjust right or left to
control movement.
Tap Capacity Overall Length
Cat No. Model No.
Inch mm
GTH-7685 111R 1/16 - 5/32 75
GTH-7686 112R 5/32 - ¼ 95
GTH-7687 113R ¼ - ½ 114
GTH-7688 3 Pc set of 111R, 112R & 113R
• Manufactured from fine quality tool steel.
• Ideally suitable for hand tapping in a very limited space.
• Left and Right hand actions are its special features.
• Jaws are hardened and tempered.
• Sets supplied in fine finished wooden box.

56 | T - TAP WRENCHES

Cat No. Model Tap Capacity O.A.L.
No. Inch mm (mm)
SOLID JAWS
GTH-7693 A 1/16 - 5/32" 1.6 - 4 60
GTH-7694 B 5/32 - 1/4" 4 - 6.3 70
GTH-7695 C 3/16 - 5/16" 4.5 - 8 80
GTH-7696 D 1/4 - 1/2" 6 - 12 88
GTH-7697 4Pc Set of Above
REPLACEABLE JAWS
GTH-7689 110A 1/16 - 5/32" 1.6 - 4 63
GTH-7690 110B 5/32 - 1/4" 4 - 6.3 75
GTH-7691 110D 1/4 - 1/2" 6 - 12 97
GTH-7692 3Pc Set of Above
• Manufactured from Fine Quality Tool Steel.
• Ideally suitable for Hand Tapping in a very limited space.
• Hardened Jaws for Longer Life.

57 | T - TAP WRENCHES 58 | TAP EXTENSIONS
PILOT SPINDLE

Tap Capacity Square Size
Cat No. Inch mm
GTH-7703 5/32 - 1/4 3 - 5.0
GTH-7704 1/4 - 1/2 5 - 7.0
GTH-7705 2pc Set Consisting of 1 each in a Box

Length Tap Capacity
Cat No.
Inch mm Inch
GTH-7707 7 180 No. 0 - 12
GTH-7708 10-3/4 275 No. 12 - 1/2
2 PC Set consisting of
GTH-7709 1 each in a Box.
• Shiny Ground finish with knurled grip chuck.
