machine TOOLS accessories
SAW ARBORS

46 | SAW HOLDER CIRCULAR

Cat No. Shank Dia. Overall Length
GSH-7583M 12mm 63.5mm
GSH-7583 1/2” 2-1/2”

• Spring Load Mechanism, with hardened shank.
• Accepts saw blades from ½” till 1” Saw holder being vertically mounted
(12/16/22/27mm). on a milling machine

47 | SAW HOLDER
MINI

Cat No. Shank Dia. Suitable bore
GSH-7000 10mm 16mm
GSH-7001 12mm 22mm

GSH-7002 Saw Holder 10mm + 3 Pcs Slitting
Saw (45mm)

48 | SAW HOLDERS 49 | STUB MILLING ARBORS

FOR GEAR CUTTERS
TAPPER SHANK
Suitable
Cat No. Shank Drawbar
Bore
GMA-7478 MT-2 16mm M10
GMA-7479 MT-2 22mm M10
GMA-7480 MT-2 27mm M10
GMA-7481 MT-2 32mm M10
GMA-7482 MT-3 16mm M12
GMA-7483 MT-3 22mm M12
GMA-7484 MT-3 27mm M12
GMA-7485 MT-3 32mm M12
Cat No. Style Drawbar Thread GMA-7486 MT-4 16mm M16
METRIC GMA-7487 MT-4 22mm M16
GMA-7488
MT-4
M16
27mm
• Accepts saw blades GSH-7581M MT-2 M10 GMA-7489 MT-4 32mm M16
from ½” till 1” GSH-7580M MT-3 M12
(12/16/22/27mm). INCHES
• Blades are firmly
secured in position GSH-7582 R8 7/16 UNF 51 | CIRCULAR SAW
with Hex Head Screw. GSH-7581 MT-2 3/8” HOLDER SET
• Supplied in grinded
plus black epoxy finish. GSH-7580 MT-3 1/2”
• Manufactured from
fine quality tool steel.
50 | SAW & GEAR CUTTER • Far saw blades from
.001” to 3/16”.
HOLDER
•
Shanks are hardened
& Ground.
• Supplied in fine
finished wooden
stand & with 2
suitable Allen Keys.
Cat No. Head Dia Shank Suitable for saw
Cat No. Shank Suitable Bore Drawbar Inch Size Blade Hole Diameter
GSH-7565 MT-2 16mm M10 GSA-7471 1/2 1/2” 1/4”
GSH-7566 MT-2 22mm M10 GSA-7472 5/8 1/2” 3/8”
1/2”
GSA-7473
3/4
1/2”
GSH-7567 MT-3 16mm M12 GSA-7474 1 5/8” 5/8”
GSH-7568 MT-3 22mm M12 GSA-7475 3 Pc set of 7471, 7472 & 7473
