machine TOOLS accessories
die holders & attachments

70 | FLOATING ROUND 71 | TAIL STOCK

DIE HOLDER
DIE HOLDER SET

Outside Shank Body Dia.
Cat No. Dia. of Die Diameter
Inch mm Inch mm Inch mm METRIC
Cat No. Morse Taper Die Holder Included
GFH-7728 13/16 20 1/2 12.7 1-1/2 38
GDH-0014 MT-2 20, 25, 30 & 38mm
GFH-7729 1 25 1/2 12.7 1-1/2 38 GDH-0015 MT-3 20, 25, 30 & 38mm
GFH-7730 1-1/2 38 3/4 19 2 51 IMPERIAL
GFH-7730A 3 Pc Set of above Cat No. Morse Taper Die Holder Included
GDH-0006 MT-2 13/16”, 1”, 1-5/16” & 1-1/2”
GDH-0007 MT-3 13/16”, 1”, 1-5/16” & 1-1/2”
72 | TAIL STOCK • This Tailstock Die Holder Set Include tapered Shank & 4 sizes of Die
Holders, completely interchangeable to fit tapered shank with the help of
DIE HOLDER SET
• a pin which allows about 1-1/2” travel.
Also included is a pin punch to knock the pin out.
• Metric Size Die Holers Available on request.
• Comes fitted in wooden box.

73 | DIE HOLDER
STRAIGHT SHANK

Shank Die
Cat No.
Size Capacity
GDH-0011 10mm 25mm
• This Die Holder Include
a straight shank for hand
operations as well as for
machines.
• Knurling is provided on the
outer body of the holder to
ease the operation by hands.

74 | LIVE TAILSTOCK

• This Tailstock Die Holder Set Include tapered Shank & 4 sizes of Die
Holders completely interchangeable.
• Metric Size Die Holders Available on request.

METRIC Cat No. Cat No. Morse Mounting Body Diameter
Cat No. Morse Taper Die Holder Included Without Chuck With Chuck Taper Thread Inch mm
GDH-0016 MT-1 20 & 25mm GLT-7887 GLT-7887C MT - 1 M14 1-5/16 34
GDH-0017 MT-2 20, 25, 30 & 38mm GLT-7888 GLT-7888C MT - 2 M14 2 50
GDH-0018 MT-3 20, 25, 30 & 38mm GLT-7889 GLT-7889C MT - 3 M14 2-5/16 60
IMPERIAL GLT-7890 GLT-7890C MT - 4 M14 2-1/2 63
Cat No. Morse Taper Die Holder Included • Manufactured from high grade steel hardened point to impart extra
GDH-0008 MT-1 13/16", 1" • strength.
GDH-0009 MT-2 13/16", 1", 1-5/16" & 1-1/2" These have single row bearings & Taper rolling to take up radial load and
thrust bearings to absorb axial loads.
GDH-0010 MT-3 13/16", 1", 1-5/16" & 1-1/2" • 3 Jaw self centring 50mm Lathe Chuck.
