machine TOOLS accessories
centers

75 | LATHE CENTERS 76 | BEVEL REVOLVING PIPE

CENTERS
AS PER DIN 806

• Machining Pipes And Similar
Hollow Shaft Materials With a
High Thrust Capacity.
• Bevel Section Is Ground After assembly Running In Its Own Bearing.
• Designed to hold hollow & pipe Works.
• Solid Construction with no moving parts and fully hardened. • Manufactured from heat treated high carbon Alloy steel.
• Tip hardened to 60-63 HRC and included angle at tip is 60 Degree.
• Hardened High Speed centers ensure long life. Cat No. Morse Taper Capacity (mm)
• Carbide tipped centers give longer tool life & require less grinding. Shank Minimum Maximum
• Covers widest range of center hole sizes. GRC-7890 MT-2 19 80
• Eliminates special centers. GRC-7894 MT-2 26 50
• Point Angle - 60. GRC-7895 MT-2 38 75
FULL GRC-7891 MT-3 20 95
Cat No. Cat No. Morse Overall Length GRC-7896 MT-3 26 50
GRC-7897
75
38
MT-3
Carbon Steel Carbide Tipped Taper Inch mm GRC-7898 MT-3 34 100
GDC-7842 GDC-7849 MT-0 2-7/8" 73 GRC-7892 MT-4 29 125
GDC-7843 GDC-7850 MT-1 3-5/16" 84 GRC-7899 MT-4 26 50
GDC-7844 GDC-7851 MT-2 4-3/16" 104 GRC-7900 MT-4 38 75
GDC-7845 GDC-7852 MT-3 5-1/4" 133 GRC-7901 MT-4 51 88
GDC-7846 GDC-7853 MT-4 6-1/2" 165 GRC-7902 MT-4 64 100
GDC-7847 GDC-7854 MT-5 8" 203 GRC-7903 MT-4 76 150
GDC-7848 GDC-7855 MT-6 10-5/8" 270 GRC-7893 MT-5 32 150
GRC-7904 MT-5 51 88
HALF GRC-7905 MT-5 64 100
Cat No. Cat No. Morse Overall Length GRC-7906 MT-5 76 150
Carbon Steel Carbide Tipped Taper Inch mm GRC-7907 MT-6 64 100
GDC-7863 GDC-7873 MT-1 3-5/16" 84 GRC-7908 MT-6 76 150
GDC-7864 GDC-7874 MT-2 4-3/16" 104 GRC-7909 MT-6 102 200
GDC-7865 GDC-7875 MT-3 5-1/4" 133
GDC-7866 GDC-7876 MT-4 6-1/2" 165
GDC-7867 GDC-7877 MT-5 8" 203 78 | REVOLVING CENTER

77 | MINI LIVE CENTERS

SLIM BODY

Morse Body Diameter Point Diameter Overall Length
Cat No. Taper Inch mm Inch mm Inch mm
GRC-7878 MT - 1 1-5/16 34 11/16 18 4-3/4 120
GRC-7879 MT - 2 2 50 27/32 21 5-7/8 148
GRC-7880 MT - 3 2-5/16 60 15/16 24 7-1/4 185
GRC-7881 MT - 4 2-1/2 63 1-1/8 28 8-5/8 220
Cat No. Morse Taper Body Dia. O.A.L. GRC-7882 MT - 5 3 75 1-1/2 36 10-1/4 260
GRC-7886 MT-0 23mm 90mm GRC-7883 MT - 6 4 100 2-1/8 53 14 355
GRC-7887 MT-1 23mm 90mm
• Manufactured from high grade steel hardened point to impart extra
• Body is constructed from case hardened steel. strength.
• Ecentricity between .005 - .010 µ • These have single row bearings & Taper rolling to take up radial load and
• #7887 is suitable For Emco Compact 5 Lathe & Similar Sized mini Lathes. • thrust bearings to absorb axial loads.
Recommended for applications upto a maximum of 2000rpm.
