machine TOOLS accessories
lathe toolings

79 | REVOLVING CENTER

MULTI POINTS 7 TIPS

Cat No. Morse Taper
GRC-0021 MT-1
GRC-0022 MT-2
GRC-0023 MT-3
GRC-0024 MT-4

• Set Contents - 5 Diff. live centers, 1 Pipe Center, 1 Female Center & 1
Ejecting Key.
• Assembled with three bearings.
• Ecentricity between .005 - .010 µ
• Body is constructed from hardened and ground steel.
• Widely used by Modelmakers & Woodworkers on mini lathes.

80 | TEST BARS / TEST
MANDRELS

Cat No. Morse Taper
GTB-0011 MT-1
GTB-0022 MT-2 • Hardened and ground.
GTB-0033 MT-3 • Parallel and centered at
body ends.
GTB-0044 MT-4
• Fits between headstock
GTB-0055 MT-5 and tailstock.

81 | QUICK CHANGE TOOLPOST
5PC SET

Cat No. Block Dimension Mounting Bore Contents
l x w x h
1 x Mounting Block
2 x Standard Holders
GTP-T37 60x60x37mm 7/16" (11.2mm) 1 x Parting Holder
1 x Boring Holder
1 x Parting Blade
• Manufactured from hardened Alloy Steel and precision ground surface.
• Set supplied with suitable parting blade and spanner.

SPARE HOLDERS

Standard Holder Boring Holder Parting Holder Standard Holder Extended
Cat No. Capacity Cat No. Capacity Cat No. Capacity Cat No. Capacity
GTP-S37 12mm GTP-B37 12mm GTP-P37 For 3/32x1/2” GTP-E37 Capacity 12mm,
Blade (12.7mm) O.A.L. 3-1/2”

www.garvintools.com 25
