Page 15 - Garvin-Machine

machine TOOLS accessories
PARTING TOOL HOLDERS

Shank
23 | PARTING & GROOVING GPT-1000 Shank Inches GTN-3
Insert
Cat No.
mm
HOLDERS
5/16"
8
GPT-1001 10 3/8" GTN-3
GPT-1002 12 1/2" GTN-3
SPARE INSERT GPT-1003 14 9/16" GTN-3
Cat No. Type GPT-1004 16 5/8" GTN-3
GTN-3 3mm GPT-1005 20 3/4" GTN-3
• Supplied with GTN-3 Insert and Ejecting Key.

24 | PARTING TOOL HOLDER

MINI CLAMP TYPE

Cat No. Shank
GPT-0019 8mm
GPT-0020 10mm
GPT-0021 12mm
SPARE HSS PARTING BLADE
• Supplied with Blade.
• Positive Locking of Blade with Cat No. Size
thicker Clamp to Hold Blade. GTB-4000 1.5x8.25x73mm

25 | PARTING TOOL HOLDERS
MINI

Cat No. Shank Suitable Blade
GPT-0016 6x6x80mm 1.45 x 5 x 62mm SPARE BLADES
GPT-0017 8x8x80mm 1.45 x 5 x 62mm Cat No.
GPT-0018 10x10x80mm 1.45 x 5 x 62mm GTB-3909

26 | PARTING TOOL HOLDERS SPARE BLADES
CLAMP TYPE
Cat No. Suitable For Shank
GTB-3902 10mm (3/8")
GTB-3905 12mm (1/2")

Suitable Blade
Cat No. Shank Length
Metric Inch
GPT-0044 10mm (3/8") 55mm (2-3/16") 2.5 x 12.7mm 3/32 x 1/2"
GPT-0045 12mm (1/2") 55mm (2-3/16") 3 x 19mm 1/8 x 3/4"

27 | PARTING TOOL HOLDERS
“KOMET” TYPE
SPARE BLADES
Cat No. Cat No. Shank Size Suitable Blade Suitable For
Holder With Blade mm mm Cat No. Shank
GTH-0110 GTH-0115 10x10x80mm 2x8x70mm GTH-0111 10x10x80mm
GTH-0010 GTH-0116 11x16x100mm 2x8x80mm GTH-0112 11x16x100mm
GTH-0011 GTH-0117 11x18x125mm 2.5x10x100mm GTH-0113 11x18x125mm
GTH-0012 GTH-0118 13x22x135mm 3.5x12x125mm GTH-0114 13x22x135mm

www.garvintools.com 13
