TURNING TOOL HOLDERS

17 | TURNING TOOL Cat No. Model # Inch Capacity mm Inch mm
Overall Length
HOLDERS / ADJUSTABLE
GHT-7393
5
GHT-7394 # 523 3/16 to 1/4 4.76 to 6.35 5-1/2 127
# 543
6.35 to 7.93
1/4 to 5/16
140
GHT-7395 # 533 5/16 to 3/8 7.93 to 9.32 6 152
GHT-7396 # 553 3/8 to 1/2 9.52 to 12.7 8 203
• These tool holders offer maximum effectiveness by means of a carefully
machined groove with relieved corners which enables the tool bit to rest on a
really flat surface.
• Properly hardened & grinded & Finely blackodized.

18 | MINI TURNING TOOL

3 PC SET

Cat No. Shank Toolbit SPARE HSS TOOLBIT
Size
Cat No.
8mm
GTH-7057 (5/16") 3.15mm GTB-4001
(1/8")

19 | UNIVERSAL TOOL HOLDER Straight CAPACITY (SQUARE TOOL) Holder Size
Cat No.
mm
mm
Inch
GHT-7393A 1/4 6 110 x 12 x 16
GHT-7394B 3/8 9.5 120 x 14 x 18
GHT-7395C 1/2 12.7 145 x 18 x 20
GHT-7396D 5/8 16 175 x 20 x 25
GHT-7396E 3/4 19 250 x 25 x 32

• Manufactured from high-grade steel, fully hardened.
• Supplied with suitable allen keys & nuts but without tool bit.
• Tool bit can be hold in three different directions.

20 | PARTING TOOL HOLDER
ECLIPSE TYPE

Cat No. Ref # Shank Capacity
GHT-7398 653S 1/2 x 1 x 6" 1/2" - 5/8"
GHT-7399 673S 5/8 x 1-3/8 x 7" 3/4" - 7/8"
GHT-7400 693S 3/4" x 1-11/16 x 7-1/2" 1" - 1-1/8"

• Manufactured from high-grade steel, fully hardened.
• Supplied with suitable wrench.
