Vices and milling tABLES
precision vices

GRT-0003
19 MILLING MACHINE VICE 20 MILLING MACHINE VICE
2 WAY

SWIVEL BASE
Jaw Width Jaw Opening Jaw Depth
Cat No.
Inch mm Inch mm Inch mm
GMV-0105 2 50 2 50 1 25
GMV-0109 3 75 3 75 1-1/4 33
GMV-0106 4 100 4 100 1-1/2 38
GMV-0107 5 125 5 125 2 50 TILT & SWIVEL
GMV-0108 6 150 6 150 2-1/8 53 Jaw Width Jaw Opening Jaw Depth
Cat No.
Inch mm Inch mm Inch mm
FIXED BASE GTV-0112 2 50 2 50 1 25
Jaw Width Jaw Opening Jaw Depth GTV-0116 3 75 3 75 1-1/4 33
Cat No.
Inch mm Inch mm Inch mm GTV-0113 4 100 4 100 1-1/2 38
GMV-0100 2 50 2 50 1 25
GMV-0104 3 75 3 75 1-1/4 33 GTV-0118 5 125 5 125 2 50
GMV-0101 4 100 4 100 1-1/2 38 • Robust construction manufactured from closed grain high tensile
GMV-0102 5 125 5 125 2 50 seasoned cast iron.
GMV-0103 6 150 6 150 2-1/8 53 • Positive locking to withstand heavy loads.
• Manufactured from closed grain high tensile seasoned cast iron. • Horizontal swivel base model has 360o graduations.
• Horizontal swivel base model has 3600 graduations. • Vertical swivel movement 90o
• Jaws are hardened and ground. • Jaws are hardened and ground.
• Vice can be set at any angle along with the vertical axis. • Vice can be set at any angle along with the vertical axis.

21 UNIVERSAL MACHINE VICE

3 WAY TILT, SWIVEL & ROTATE
Jaw Width Jaw Opening Jaw Depth
Cat No.
Inch mm Inch mm Inch mm
GUV-0117 2 50 2 50 1 25
GUV-0118 3 75 3 75 1-1/4 33
GUV-0116 4 100 4 100 1-1/2 38
• Perfect piece of workmanship.
• Job can be held firmly at any desired compound
table.
• Low height construction makes these useful even on the most
complicated grinding jobs.
• Horizontal swivel base model has 3600 graduations allows
complete rotation along vertical axis.
• The third angular slide with a moving axis allows for any setting
in 3D plane.
• Jaws are hardened and ground.
• Manufactured from closed grain high tensile seasoned cast iron.

www.garvintools.com 9
