GRT-0003
ROTARY TABLE
06 HORIZONTAL & VERTICAL
4-3/8” / 110mm

Table Dia Overall Height Vertical T - Slot
Center Gear Center
Cat No. Type Width
Inch mm Inch mm Height (mm) Ratio Sleeve
mm
GRT-HV04 H & V 4-3/8 110 3-1/8 80 86 17 90:1 MT-2
GRT-HV04C Rotary Table + Clamping Kit
GRT-HV04S Rotary Table + Dividing Plate Set
GRT-HV04ST Rotary Table + Dividing Plate Set + Tailstock
• Engage & Disengage Function for manual indexing.

07 ROTARY TABLE
TILTING
4-3/8” / 110mm

Table Dia Overall Height Vertical
Center T - Slot Gear Center
Cat No. Type Width
Inch mm Inch mm Height (mm) Ratio Sleeve
mm
GRT-HV04T TILTING 4-3/8 110 5 126 84 17 90:1 MT-2
GRT-HV04TC Rotary Table + Clamping Kit
GRT-HV04TD Rotary Table + Dividing Plate Set
GRT-HV04TT Rotary Table + Dividing Plate Set + Tailstock
• Can be Tilted from 0 to 180⁰.
• Engage & Disengage Function for manual indexing.

SUITABLE ACCESSORIES FOR ABOVE ROTARY TABLE

A. DIVIDING PLATE B. TAILSTOCK C. MINI CLAMPING KIT - M8

Cat No. Adj. Height Min - Max Cat No.
Cat No.
GDP-0005 Inch mm GRT-RT6
GTS-0004 3-5/8 - 5 93 -125
No. Of Holes of Dividing Plates are as follows :
Plate ‘A’ - 15, 16, 17, 18, 19, 20
Plate ‘B’ - 21, 23, 27, 29, 31, 33
Plate ‘C’ - 37, 39, 41, 43, 47, 49
Comes Complete with Washers, Crank Handle & Screws.
