Vices and milling tABLES
Rotary tables & accessories

01 ROTARY TABLE 02 ROTARY TABLE
HORIZONTAL & VERTICAL
TILTING
3” / 75mm 3” / 75mm

With Chuck
With Chuck

Table Dia Overall Height T - Slot Table Dia Overall Height T - Slot
Cat No. Type Width Gear Cat No. Type Width Gear
Inch mm Inch mm (mm) Ratio Inch mm Inch mm (mm) Ratio
GRT-0003 H & V 3 75 1-3/4 45 13 36:1 GRT-00T3 TILTING 3 75 2-1/8 55 13 36:1
GRT-0003CK Rotary Table + Clamping Kit GRT-003TCK Rotary Table + Clamping Kit
GRT-0003C Rotary Table + 3 Jaw 65mm Self Centring Lathe Chuck + Back Plate GRT-00T3C Rotary Table + 3 Jaw 65mm Self Centring Lathe Chuck + Back Plate
GRT-0003C4 Rotary Table + 4 Jaw 70mm Independent Lathe Chuck + Back Plate GRT-00T3C4 Rotary Table + 4 Jaw 70mm Independent Lathe Chuck + Back Plate

SUITABLE ACCESSORIES FOR ABOVE ROTARY TABLE

A. BACKPLATE B. LATHE CHUCK C. LATHE CHUCK

Dia Mounting Dia Mounting Dia Mounting
Cat No. Cat No. Cat No.
Inch mm Thread Inch mm Thread Inch mm Thread
GRT-BP5514 2-1/4 55 M14 GLC-8241 2-1/2 65 M14 GLC-8243 2-3/4 70 M14
D. ADJUSTABLE TAILSTOCK E. MINI CLAMPING KIT M5 F. T NUTS

Adj. Height (Min - Max) Cat No. Cat No. Thread Size
Cat No.
mm GRT-CT3 GRT-TN2 M5 12 x 12mm
GTS-0005 42 - 92
