Vices and milling tABLES
precision vices

22 MILLING MACHINE VICE • Robust construction
manufactured from closed grain
3 WAY
• high tensile seasoned cast iron.
Positive locking to withstand
2 WAY TILT & SWIVEL heavy loads.
Jaw Width Jaw Opening Jaw Depth • Horizontal swivel base model has
Cat No. 360o graduations.
Inch mm Inch mm Inch mm •
GTV-0117 2 50 2 50 1 25 • Vertical indexing 90o.
Tilting range 45o.
GTV-0119 3 75 3 75 1-1/4 33 • Jaws are hardened and ground.
GTV-0115 4 100 4 100 1-1/2 38 • Vice can be set at any angle along
GTV-0120 5 125 5 125 2 50 with the vertical axis.

23 SELF CENTRING 24 MODULAR MACHINE VICE
MACHINE VICE
SET OF 3 PCS

SWIVEL BASE Interchange Vice or T-Slot Table as required
Jaw Width Jaw Opening Jaw Depth
Cat No.
Inch mm Inch mm Inch mm
GSV-0119 2 50 2 50 1 25
GSV-0118 3 75 3 75 1-1/4 33
GSV-0118A 4 100 4 100 1-1/2 38
GSV-0120 5 125 5 125 2 50
GSV-0118B 6 150 6 150 2-1/8 53
FIXED BASE VICE TABLE
Jaw Width Jaw Opening Jaw Depth Jaw Jaw Jaw Depth Height
Cat No. Cat No. Width Opening
Inch mm Inch mm Inch mm Inch mm Inch mm Inch mm Inch mm
GSV-0121 2 50 2 50 1 25 GMV-0115 2 50 2 50 1 25 5x4x7/8 125x100x22
GSV-0122 3 75 3 75 1-1/4 33 GMV-0116 3 75 3 75 1-1/4 32 8x6x1-1/8 200x150x28
GSV-0123 4 100 4 100 1-1/2 38 GMV-0117 4 100 4 100 1-1/2 38 10x8x1-9/16 250x200x40
GSV-0124 5 125 5 125 2 50 • Robust construction manufactured from closed grain high tensile
GSV-0125 6 150 6 150 2-1/8 53 seasoned cast iron.
• Allows self centring for accurate centring of jobs automatically. • Used for milling, shaping, drilling, grinding etc.
• The special design allows accurate setting up of jobs with only a single • This vice can be replaced by t-slot table provided in the set.
machine setting. • Tilting movement 00 - 45o
• A milled slot in the vice base allows for accurate location of the vice on the • Horizontal movement 00 - 90o
machine table using rectangular locating nuts. • Fixed rotary base provide with 360o rotation.
• Opposite threads for quick and accurate centring. • Jaws are hardened and ground.

SELF CENTRING • Allows self centring for accurate centring of
jobs automatically.
25 MACHINE VICE • The special design allows accurate setting up
LOW PROFILE • of jobs with only a single machine setting.
A milled slot in the vice base allows for
accurate location of the vice on the machine
table using rectangular locating nuts.
Jaw Width Jaw Opening Jaw Depth Height • Opposite threads for quick and accurate
Cat No. centring.
Inch mm Inch mm Inch mm Inch mm •
GSV-0126 2 50 3-1/8 78 1-1/8 28 2-3/8 60 The vice is specially useful in applications
where the same operation is to be performed
GSV-0127 3 75 5 125 1-3/8 35 3 75 on work pieces of varying sizes.
