precision TOOLS
VEE BLOCKS

71 | MAGNETIC VEE BLOCKS

• Supplied in matched pairs in fine finished wooden box.
• Surface is precision ground.
• The strong magnet is controlled by on / off switch.

Cat No. Cat No. Length Width Height Big V Small V
SINGLE PAIR Inch mm Inch mm Inch mm Inch mm Inch mm
GMB-6590 GMB-6594 2- ¾ 70 2-1/8 54 2-7/8 73 1-1/2 38 3/4 19
GMB-6591 GMB-6595 4 100 2-3/4 70 3-3/4 95 2 50 3/4 19
GMB-6593 GMB-6597 6 150 3 75 3-3/4 95 2-1/4 55 1 25

72 | TRIPLE VEE BLOCKS

Suitable for
Length Width Height
Cat No. Dia.
mm mm mm mm
GBV-6635 50 20 14 5-33
GBV-6636 75 24 35 6-45
GBV-6637 100 33 52 8-60
GBV-6638 125 44 69 8-75
• Manufactured from steel.
• Every angle 90O.
• Matched Pairs.

73 | ELONGATED VEE BLOCKS

Cat No. L x W x H V Capacity
mm mm
GBV-7091 75x40x30 5-40
GBV-7092 100x47x40 5-55
GBV-7093 150x55x45 5-60
GBV-7094 200x65x55 5-75
• All sides precision ground parallel and square.
• “V” Grooves ground central & parallel and square.
• Perfect alignment in matched pair.
• Holds the square and round work.
• Elongated ‘V’ Blocks are suitable for marking checking,Drilling and milling.
