precision TOOLS
Setup tools

81 | ENGINEER’S STEEL

PARALLELS & SETS

No. of
Cat No. Length Height Thickness Pairs
GSP-6778 100mm 10-14-18-22-26-30-34-38- 4mm 9
42mm
10-14-18-22-26-30-34-38-
GSP-6779 160mm 42mm 4mm 9
GSP-6780 120mm 14-16-18-20-22-24-26-28- 10mm 12
30-32-35-40mm
14-16-18-20-22-24-26-28-
GSP-6781 150mm 30-32-35-40-45-50mm 10mm 14
• Very useful for Milling & drilling.
• Made from alloy steel.
• Properly hardened & ground.
• Very useful in tool rooms for inspection, measuring, laying off & setup
jobs.
• Supplied in matched pairs.
• Sets Supplied in fine finished wooden Box.

82 | WAVY PARALLEL

SET OF 8 PAIRS

Cat No. Length Height
GWP-5205 110mm 9, 11, 13, 15, 17, 19 & 21mm
GWP-5206 110mm 25, 27, 29, 31, 33, 35 & 37mm

83 | V SINE BAR 84 | SINE BARS

Distance Between
Cat No. Model No. Width
Rollers
GBS-6935 AA 15/16” 5”
GBS-6936 AA 1” 10”
GBS-6937 BB 1” 2-1/2”
GBS-6938 BB 1” 5”
GBS-6939 CC 30 mm 100 mm
Cat No. Length Width GBS-6940 CC 30 mm 200 mm
GSB-7090 5” 1-1/4” GBS-6941 DD 7/32” 3”
• Hardened & Ground. • Made of high quality alloy steel.
• Clamp Included. • Distance between center of rolls + - .004”.
• Accurate to .0005”. 1” Round capacity. • Very useful tool for measurements & angular inspection.
