REAMERS

161 | ADJUSTABLE HAND REAMERS

Range No. of
Cat No. American Size Industrial Code
Inch mm Blades
GAR-2486 8/A HV 1/4 to 9/32 6.35 to 7.14 4
GAR-2487 7/A HW 9/32 to 5/16 7.14 to 7.94 4
GAR-2488 6/A HZ 5/16 to 11/32 7.94 to 8.73 4
GAR-2489 5/A HY 11/32 to 3/8 8.73 to 9.52 5
GAR-2490 4/A H1 3/8 to 13/32 9.52 to 10.32 6
GAR-2491 3/A H2 13/32 to 7/16 10.32 to 11.11 6
GAR-2492 2/A H3 7/16 to 15/32 11.11 to 11.91 6
GAR-2493 A H4 15/32 to 17/32 11.91 to 13.49 6
GAR-2494 B H5 17/32 to 19/32 13.49 to 15.08 6
GAR-2495 C H6 19/32 to 21/32 15.08 to 16.67 6
GAR-2496 D H7 21/32 to 23/32 16.67 to 18.26 6
GAR-2497 E H8 23/32 to 25/32 18.26 to 19.84 6
GAR-2498 F H9 25/32 to 27/32 19.84 to 21.43 6
GAR-2499 G H10 27/32 to 15/16 21.43 to 23.81 6
GAR-2500 H H11 15/16 to 1-1/16 23.81 to 26.99 6
GAR-2501 I H12 1-1/16 to 1-3/16 26.99 to 30.16 6
GAR-2502 J H13 1-3/16 to 1-11/32 30.16 to 34.13 6
GAR-2503 K H14 1-11/32 to 1-1/2 34.13 to 38.10 6
GAR-2504 L H15 1-1/2 to 1-13/16 38.10 to 46.04 6
GAR-2505 M H16 1-13/16 to 2-7/32 46.04 to 56.36 6
GAR-2506 N H17 2-7/32 to 2-3/4 56.36 to 69.85 6
GAR-2507 O H18 2-3/4 to 3-11/32 69.85 to 84.93 6
GAR-2508 P H19 3-11/32 to 4 84.93 to 100 6
GAR-2509 Q H20 4 to 4-3/4 100 to 120 6
GAR-2509A R H21 4-3/4 to 5-1/2 120 to 140 6

162 | HSS PARTING TOOL 163 | SETS OF ADJUSTABLE
BITS
HAND REAMERS
CUT OFF BLADES

A B C D E F G H
Cat No. Size In Inches
M - 2GRADE 5% Cobalt Cat No. Range
GTB-3901 GTB-3914 1/16 x 5/16 x 3 1/2 GAR-3801 Set of 3 Reamers (4/A to 2/A)
GTB-3902 GTB-3915 3/32 x 1/2 x 4 GAR-3802 Set of 4 Reamers (8/A to 5/A)
GTB-3903 GTB-3916 3/32 x 1/2 x 4 1/2 GAR-3803 Set of 7 Reamers (8/A to 2/A)
GTB-3904 GTB-3917 3/32 x 5/8 x 5 GAR-3804 Set of 6 Reamers (A to F)
GTB-3905 GTB-3918 1/8 x 3/4 x 6 GAR-3805 Set of 8 Reamers (A to H)
GTB-3906 GTB-3919 1/8 x 7/8 x 6 GAR-3806 Set of 6 Reamers (C to H)
GTB-3907 GTB-3920 1/8 x 7/8 x 7 GAR-3807 Set of 9 Reamers (C to K)
GTB-3908 GTB-3921 1/8 x 1" x 8 GAR-3808 Set of 11 Reamers (A to K)
GTB-3909 GTB-3922 3/16 x 3/4 x 6 GAR-3809 Set of 16 Reamers (4/A to M)
GTB-3910 GTB-3923 3/16 x 1 x 6 GAR-3810 Set of 9 Reamers (A to I)
GTB-3911 GTB-3924 3/16 x 1 x 6 1/2 GAR-3811 Set of 5 Reamers (I to M)
GTB-3912 GTB-3925 3/16 x 1 1/8 x 7
GTB-3913 GTB-3926 3/16 x 1 x 8 (Each Set is Supplied in Finished Wooden Box)
