tAPPING & THREADING TOOLS

CARBON TAPS
167 | B. S.W. / B.S.F. 168 | CARBON ROUND DIES
B.S.W. / B.S.F.
AS PER ASME / ANSI B94.9

Cat No. Outer Dia.
Cat No. Set of Three Right hand Die Set Left hand Die Set Size of Dies
Plug Bottoming Taper Plug, Bottom Size GDR-3684 GDR-3733 1/16" -60 B.S.W. 13/16"
& Taper Taps
GTC-3098 GTC-3146 GTC-3194 GTC-3243 1/16" -60 B.S.W. GDR-3685 GDR-3734 3/32" -48 B.S.W. 13/16"
GTC-3099 GTC-3147 GTC-3195 GTC-3244 3/32" -48 B.S.W. GDR-3686 GDR-3735 1/8" -40 B.S.W. 13/16"
GTC-3100 GTC-3148 GTC-3196 GTC-3245 1/8" -40 B.S.W. GDR-3687 GDR-3736 5/32" -32 B.S.W. 13/16"
GTC-3101 GTC-3149 GTC-3197 GTC-3246 5/32" -32 B.S.W. GDR-3688 GDR-3737 3/16" -24 B.S.W. 1"
GTC-3102 GTC-3150 GTC-3198 GTC-3247 3/16" -24 B.S.W. GDR-3689 GDR-3738 3/16" -32 B.S.F. 1"
GTC-3103 GTC-3151 GTC-3199 GTC-3248 3/16" -32 B.S.F. GDR-3690 GDR-3739 7/32" -24 B.S.W. 1"
GTC-3104 GTC-3152 GTC-3200 GTC-3249 7/32" -24 B.S.W. GDR-3691 GDR-3740 7/32" -28 B.S.F. 1"
GTC-3105 GTC-3153 GTC-3201 GTC-3250 7/32" -28 B.S.F. GDR-3692 GDR-3741 1/4" -20 B.S.W. 1"
GTC-3106 GTC-3154 GTC-3202 GTC-3251 1/4" -20 B.S.W. GDR-3693 GDR-3742 1/4" -26 B.S.F. 1"
GTC-3107 GTC-3155 GTC-3203 GTC-3252 1/4" -26 B.S.F. GDR-3694 GDR-3743 9/32" -20 B.S.W. 1"
GTC-3108 GTC-3156 GTC-3204 GTC-3253 9/32" -20 B.S.W. GDR-3695 GDR-3744 9/32" -26 B.S.F. 1"
GTC-3109 GTC-3157 GTC-3205 GTC-3254 9/32" -26 B.S.F. GDR-3696 GDR-3745 5/16" -18 B.S.W. 1"
GTC-3110 GTC-3158 GTC-3206 GTC-3255 5/16" -18 B.S.W.
GTC-3111 GTC-3159 GTC-3207 GTC-3256 5/16" -22 B.S.F. GDR-3697 GDR-3746 5/16" -22 B.S.F. 1"
GTC-3112 GTC-3160 GTC-3208 GTC-3257 3/8" -16 B.S.W. GDR-3698 GDR-3747 3/8" -16 B.S.W. 1"
GTC-3113 GTC-3161 GTC-3209 GTC-3258 3/8" -20 B.S.F. GDR-3699 GDR-3748 3/8" -20 B.S.F. 1"
GTC-3114 GTC-3162 GTC-3210 GTC-3259 7/16" -14 B.S.W. GDR-3701 GDR-3749 7/16" -14 B.S.W. 1-1/2"
GTC-3115 GTC-3163 GTC-3211 GTC-3260 7/16" -18 B.S.F. GDR-3702 GDR-3750 7/16" -18 B.S.F. 1-1/2"
GTC-3116 GTC-3164 GTC-3212 GTC-3261 1/2" -12 B.S.W. GDR-3703 GDR-3751 1/2" -12 B.S.W. 1-1/2"
GTC-3117 GTC-3165 GTC-3213 GTC-3262 1/2" -16 B.S.F. GDR-3704 GDR-3752 1/2" -16 B.S.F. 1-1/2"
GTC-3118 GTC-3166 GTC-3214 GTC-3263 9/16" -12 B.S.W. GDR-3705 GDR-3753 9/16" -12 B.S.W. 1-1/2"
GTC-3119 GTC-3167 GTC-3215 GTC-3264 9/16" -16 B.S.F. GDR-3706 GDR-3754 9/16" -16 B.S.F. 1-1/2"
GTC-3120 GTC-3168 GTC-3216 GTC-3265 5/8" -11 B.S.W. GDR-3707 GDR-3755 5/8" -11 B.S.W. 1-1/2"
GTC-3121 GTC-3169 GTC-3217 GTC-3266 5/8" -14 B.S.F. GDR-3708 GDR-3756 5/8" -14 B.S.F. 1-1/2"
GTC-3122 GTC-3170 GTC-3218 GTC-3267 11/16" -11 B.S.W. GDR-3709 GDR-3757 11/16" -11 B.S.W. 1-1/2"
GTC-3123 GTC-3171 GTC-3219 GTC-3268 11/16" -14 B.S.F. GDR-3710 GDR-3758 11/16" -14 B.S.F. 1-1/2"
GTC-3124 GTC-3172 GTC-3220 GTC-3269 3/4" -10 B.S.W. GDR-3711 GDR-3759 3/4" -10 B.S.W. 1-1/2"
GTC-3125 GTC-3173 GTC-3221 GTC-3270 3/4" -12 B.S.F. GDR-3712 GDR-3760 3/4" -12 B.S.F. 1-1/2"
GTC-3126 GTC-3174 GTC-3222 GTC-3271 13/16" -10 B.S.W. GDR-3713 GDR-3761 13/16" -10 B.S.W. 2"
GTC-3127 GTC-3175 GTC-3223 GTC-3272 13/16" -12 B.S.F. GDR-3714 GDR-3762 13/16" -12 B.S.F. 2'
GTC-3128 GTC-3176 GTC-3224 GTC-3273 7/8" -9 B.S.W.
GTC-3129 GTC-3177 GTC-3225 GTC-3274 7/8" -11 B.S.F GDR-3715 GDR-3763 7/8" -9 B.S.W. 2"
GTC-3130 GTC-3178 GTC-3226 GTC-3275 15/16" -9 B.S.W. GDR-3716 GDR-3764 7/8" -11 B.S.F. 2"
GTC-3131 GTC-3179 GTC-3227 GTC-3276 15/16" -11 B.S.F. GDR-3717 GDR-3765 15/16" -9 B.S.W. 2"
GTC-3132 GTC-3180 GTC-3228 GTC-3277 1" -8 B.S.W. GDR-3718 GDR-3766 15/16" -11 B.S.F. 2"
GTC-3133 GTC-3181 GTC-3229 GTC-3278 1" -10 B.S.F. GDR-3719 GDR-3767 1" -8 B.S.W. 2"
GTC-3134 GTC-3182 GTC-3230 GTC-3279 1-1/8" -7 B.S.W. GDR-3720 GDR-3768 1" -10 B.S.F. 2"
GTC-3135 GTC-3183 GTC-3231 GTC-3280 1-1/8" -9 B.S.F. GDR-3721 GDR-3769 1-1/8" -7 B.S.W. 2-1/2"
GTC-3136 GTC-3184 GTC-3233 GTC-3281 1-1/4" -7 B.S.W. GDR-3722 GDR-3770 1-1/8" -9 B.S.F. 2-1/2"
GTC-3137 GTC-3185 GTC-3234 GTC-3282 1-1/4" -9 B.S.F. GDR-3723 GDR-3771 1-1/4" -7 B.S.W. 2-1/2"
GTC-3138 GTC-3186 GTC-3235 GTC-3283 1-3/8" -6 B.S.W. GDR-3724 GDR-3772 1-1/4" -9 B.S.F. 2-1/2"
GTC-3139 GTC-3187 GTC-3236 GTC-3284 1-3/8" -8 B.S.F. GDR-3725 GDR-3773 1-3/8" -6 B.S.W. 2-1/2"
GTC-3140 GTC-3188 GTC-3237 GTC-3285 1-1/2" -6 B.S.W. GDR-3726 GDR-3774 1-3/8" -8 B.S.F. 2-1/2"
GTC-3141 GTC-3189 GTC-3238 GTC-3286 1-1/2" -8 B.S.F. GDR-3727 GDR-3775 1-1/2" -6 B.S.W. 2-1/2"
GTC-3142 GTC-3190 GTC-3239 GTC-3287 1-5/8" -5 B.S.W. GDR-3728 GDR-3776 1-1/2" -8 B.S.F. 2-1/2"
GTC-3143 GTC-3191 GTC-3240 GTC-3288 1-5/8" -8 B.S.F. GDR-3729 GDR-3777 1-5/8" -5 B.S.W. 3"
GTC-3144 GTC-3192 GTC-3241 GTC-3299 1-3/4" -5 B.S.W. GDR-3730 GDR-3778 1-5/8" -8 B.S.F. 3"
GTC-3145 GTC-3193 GTC-3242 GTC-3300 1-3/4" -7 B.S.F. GDR-3731 GDR-3779 1-3/4" -5 B.S.W. 3"
GTC-4000 GTC-4004 GTC-4008 GTC-4102 1 7/8-4 1/2 B.S.W.
GTC-4001 GTC-4005 GTC-4009 GTC-4103 1 7/8 -7 B.S.F. GDR-3732 GDR-3780 1-3/4" -7 B.S.F. 3"
GTC-4002 GTC-4006 GTC-4100 GTC-4104 2" -4 1/2 B.S.W. GDR-4401 GDR-4403 2" -4.1/2 B.S.W. 4"
GTC-4003 GTC-4007 GTC-4101 GTC-4105 2" -7 B.S.F. GDR-4402 GDR-4404 2" -7 B.S.F. 4"
(Also Available in H.S.S) (Also Available in H.S.S)
