machine TOOLS accessories
tAPPING & THREADING TOOLS

169 | CARBON ROUND DIES 170 | SETS OF CARBON
ROUND DIES
B.S.P.
B.S.W. / B.S.F.

C at No. Outer Dia.
Right Hand Dies Left Hand Dies Size of Dies
GDR-4140 GDR-4152 1/8" -28 B.S.P 1" Cat No. Description
GDR-4141 GDR-4153 1/4" -19 B.S.P 1.1/2" Right hand Die Set Left hand Die Set
GDR-4142 GDR-4154 3/8 -19 B.S.P 1.1/2" GDR-3781 GDR-3790 5 PC Set 1/4" to 1/2" B.S.W.
GDR-4143 GDR-4155 1/2" -14 B.S.P 2" GDR-3782 GDR-3791 5 PC Set 1/4" to 1/2" B.S.F.
GDR-4144 GDR-4156 5/8" -14 B.S.P 2" GDR-3783 GDR-3792 10 PC Set 1/4" to 1/2" B.S.W.
GDR-4145 GDR-4157 3/4" -14 B.S.P 2" GDR-3783A GDR-3792A 10 PC Set 1/4" to 1/2" B.S.F.
GDR-3784
GDR-3793
8 PC Set 1/4" to 3/4" B.S.W.
GDR-4146 GDR-4158 7/8" -14 B.S.P 2.1/4" GDR-3785 GDR-3794 8 PC Set 1/4" to 3/4" B.S.F.
GDR-4147 GDR-4159 1" -11 B.S.P 3" GDR-3786 GDR-3795 16 PC Set 1/4" to 3/4" B.S.W.
GDR-4148 GDR-4160 1.1/8" -11 B.S.P 3" GDR-3786A GDR-3795A 16 PC Set 1/4" to 3/4" B.S.F.
GDR-4149 GDR-4161 1.1/4 -11 B.S.P 3" GDR-3787 GDR-3796 10 PC Set 1/4" to 1" B.S.W.
GDR-4150 GDR-4162 1.1/2" -11 B.S.P 4" GDR-3788 GDR-3797 10 PC Set 1/4" to 1" B.S.F.
GDR-4151 GDR-4163 2" -11 B.S.P 4" GDR-3789 GDR-3798 20 PC Set 1/4" to 1" B.S.W.
(Also Available in H.S.S) GDR-3789A GDR-3798A 20 PC Set 1/4" to 1" B.S.F.

171 | CARBON TAPS - UNC/UNF

AS PER ASME / ANSI B94.9

Cat No. Thread No. of Thread Overall Set of Three Plug,
Plug Bottoming Taper Size Flutes Length Length Bottom & Taper Taps
GTC-2920 GTC-2948 GTC-2976 1/4" -20 UNC 4 1" 2-1/2" GTC-3005
GTC-2921 GTC-2949 GTC-2977 1/4" -28 UNF 4 1" 2-1/2" GTC-3006
GTC-2922 GTC-2950 GTC-2978 5/16" -18 UNC 4 1-1/8" 2-23/32" GTC-3007
GTC-2923 GTC-2951 GTC-2979 5/16" -24 UNF 4 1-1/8" 2-23/32" GTC-3008
GTC-2924 GTC-2952 GTC-2980 3/8" -16 UNC 4 1-1/4" 2-15/16" GTC-3009
GTC-2925 GTC-2953 GTC-2981 3/8" -24 UNF 4 1-1/4" 2-15/16" GTC-3010
GTC-2926 GTC-2954 GTC-2982 7/16" -14 UNC 4 1-7/16" 3-5/32" GTC-3011
GTC-2927 GTC-2955 GTC-2983 7/16" -20 UNF 4 1-7/16" 3-5/32" GTC-3012
GTC-2928 GTC-2956 GTC-2984 1/2" -13 UNC 4 1-21/32" 3-3/8" GTC-3013
GTC-2929 GTC-2957 GTC-2985 1/2" -20 UNF 4 1-21/32" 3-3/8" GTC-3014
GTC-2930 GTC-2958 GTC-2986 9/16" -12 UNC 4 1-21/32" 3-19/32" GTC-3015
GTC-2931 GTC-2959 GTC-2987 9/16" -18 UNF 4 1-21/32" 3-19/32" GTC-3016
GTC-2932 GTC-2960 GTC-2988 5/8" -11 UNC 4 1-13/16" 3-13/16" GTC-3017
GTC-2933 GTC-2961 GTC-2989 5/8" -18 UNF 4 1-13/16" 3-13/16" GTC-3018
GTC-2934 GTC-2962 GTC-2990 3/4" -10 UNC 4 2" 4-1/4" GTC-3019
GTC-2935 GTC-2963 GTC-2991 3/4" -16 UNF 4 2" 4-1/4" GTC-3020
GTC-2936 GTC-2964 GTC-2992 7/8" -9 UNC 4 2-7/32" 4-11/16" GTC-3021
GTC-2937 GTC-2965 GTC-2993 7/8" -14 UNF 4 2-7/32" 4-11/16" GTC-3022
GTC-2938 GTC-2966 GTC-2994 1" -8 UNC 4 2-1/2" 5-1/8" GTC-3023
GTC-2939 GTC-2967 GTC-2995 1" -12 UNF 4 2-1/2" 5-1/8" GTC-3024
GTC-2940 GTC-2968 GTC-2996 1-1/8" -7 UNC 4 2-9/16" 5-7/16" GTC-3025
GTC-2941 GTC-2969 GTC-2997 1-1/8" -12 UNF 4 2-9/16" 5-7/16" GTC-3026
GTC-2942 GTC-2970 GTC-2998 1-1/4" -7 UNC 4 2-9/16" 5-3/4" GTC-3027
GTC-2943 GTC-2971 GTC-2999 1-1/4" -12 UNF 6 2-9/16" 5-3/4" GTC-3028
GTC-2944 GTC-2972 GTC-3001 1-3/8" -6 UNC 4 3" 6-1/16" GTC-3029
GTC-2945 GTC-2973 GTC-3002 1-3/8" -12 UNF 6 3" 6-1/16" GTC-3030
GTC-2946 GTC-2974 GTC-3003 1-1/2" -6 UNC 4 3" 6-3/8" GTC-3031
GTC-2947 GTC-2975 GTC-3004 1-1/2" -12 UNF 6 3" 6-3/8" GTC-3032 (Also Available in H.S.S)
