20 | SCREW PITCH GAUGES / precision TOOLS
THREAD GAUGES
precision gauges

40 | CENTER GAUGE 41 | RADIUS GAUGES

RING TYPE

• Constructed from good
quality steel.
• Packed in Attractive PVC
Jacket.
• The ring type style allows
Cat. No. Description the user to check the
GCG-7063 American Unified National Standard 60° dimensions in an easier
GCG-7064 Whitworth or English Standard 55° manner for both concave
& convex radii.
GCG-7065 2 Pc set of above two.

42 | RADIUS GAUGES

Cat No.
Range
16
GRG-6970 1/32 to 17/64 by 1/64” No of Leaves
GRG-6971 9/32 to 33/64 by 1/64” 16
GRG-6972 0.75 to 5 by 0.25 mm 18
GRG-6973 5.5 to 13 by 0.5 mm 16

43 | DIAMOND THICKNESS
• Constructed from good quality steel. GAUGE
• Each and every leaf is properly marked with size.
• Packed in attractive PVC Jacket.

Cat No. Range No of Leaves
GRG-6963 1/32” to ¼” By 1/64” 30 Cat. No. Size / mm
GRG-6964 17/64” to ½” By 1/64” 32
GRG-6965 1 to 7mm 34 GDG-7080 0 - 10
GRG-6966 7.5 to 15mm 32 GDG-7081 0 - 15
GRG-6967 15.5 to 25mm 30
GRG-6968 0.75 to 5mm By 0.25mm 18 • Spring Action between both the legs.
GRG-6969 5.5 to 13mm By 0.5mm 16 • Very useful tool for measuring the thickness of small things.

44 | MARKING GAUGE

Cat. No. Range
GMG-7185 200 mm / 8” • Graduations are properly etched to give accurate measurements.
GMG-7186 250 mm / 10” • Scale manufactured of Stainless Steel.
GMG-7187 300 mm /12” • Marking edge with metric graduations.

45 | MULTI USE RULE & GAUGE

Cat. No.
GMG-7082

Drill Point Gauge
Protractor Square Center Finder Circle Divider
